Patek Philippe has presented many new products at Watches and Wonders, and the last is probably the most amazing: the brand’s first chronograph capable of measuring a tenth of a second. It best replica watches sites to buy from is not an absolute novelty in watchmaking, it is the masterful interpretation offered by the manufacture, which takes care of the details of its creations by constantly investing in new patents that raise the standards of fine watchmaking. In addition to this and other innovations, there are many range extensions on consolidated models.
Patek 1 / 10th of a second monopusher chronograph Ref.5470P-001
Patek Philippe waited for the first day after the close of the fair to unveil its new proposal in the chronograph segment, in which it is highly specialized, and rightfully the most relevant from a technical point of view. The Patek 1/10 of a second Monopulsante Chronograph Ref. 5470P-001 is the main product novelty together with the Travel Time and proves how the Research and Development division is tireless in proposing technical innovations (and patents) with continuous jet.
The Patek Philippe Chronograph Monopulsante 1/10 of a second Ref.5470P-001 is the first Patek chronograph to measure the tenth of a second, according to an execution that involves the coexistence of two independent chronograph movements, whose measurement scales are concentric and both arranged on the dial for immediate reading.
The development of such a watch obviously requires the creation of a movement whose regulator body oscillates at 5 Hz or 36,000 vibrations per hour. Only with this architecture is it possible to pass from the measurement at 1/8 of a second typical of traditional 4Hz chronographs to that at 1/10 of a second. The conception of the 5Hz chronograph and the 1/10 reading is not a novelty in watchmaking, as anticipated. His execution is.
The movement features two independent chronograph movements; the first offers the classic display with central seconds and totalizer of the first 30 minutes chrono (counter at three o’clock), the second, coaxial to the first, has a concentric scale to that of the seconds, so as to offer an immediate reading of the seconds totalizer and tenths using the scale on the flange and reading between two red marks. This display is patented.
Technically and visually, the red lacquered tenth of a second hand completes a complete revolution of the dial in twelve seconds. As per Patek tradition, it is not only the complication that emerges, but its excellent execution, whose maniacal level of care and fine-tuning aims to make the user experience excellent. The project requirements therefore provide for a perfect measurement experience over the entire period of use, that is, for all thirty minutes of timing, which we summarize in the following paragraph.
The caliber CH 29-535 PS 1/10
It starts with the backbone of the CH 29-535 PS hand-wound movement with rattrapante function, although the engineers have worked to reduce its overall size. Compared to the latter, it is slightly thinner (6.96 mm versus 7.1 mm) despite the presence of the double chronograph requiring a considerable amount of energy to activate the two independent movements and theoretically bulk up. Patek releases detailed information on how it has achieved its goals of performance, precision, reliability. It is an appreciable technical guide aimed at the most refined collector.
For example, the engineers have reduced the diameter of the barrel shaft and increased the number of revolutions of the mainspring. For the regulating organ, we rely on the Oscillomax® patent, which includes the Spiromax® hairspring, the Pulsomax® escapement and the Gyromax® balance wheel. The latter is made of Silinvar®, a derivative of silicon. Summary: the daily deviation falls within a window of -3 / + 2 seconds per day.
Designed to ensure perfect synchronism of the chrono hands, minimizing any (microscopic) effect of oscillation of the spheres during the transients of starting, stopping, and resetting (rather than starting, stopping, restarting), the caliber has also been designed to withstand the bumps. Finally, the complication is managed via a single button inserted at two o’clock. The caliber is mounted inside a platinum case 41 mm wide and 13.68 mm thick from the edge of the upper sapphire crystal to that of the lower sapphire crystal. For this chronograph alone, Patek Philippe has filed seven new exclusive patents regarding the movement. The price is on request.
Travel Time Annual Calendar REF. 5326G-001
Before the presentation of the monopusher chronograph, the “main piece” of the Patek Philippe novelties was the Travel Time REF Annual Calendar. 5326G-001. Although there are obvious, and replica watches uk trusted deaiers not hidden, references to the Calatrava in the design of the case and lugs, even if the name would seem excluded from the official naming of the new model, we find the Patek interpretation of the Travel Time function combined for the first one as a central technical and aesthetic argument. aimed at the annual calendar, introduced by Patek in 1996.best replica watches sites to buy from
The result is greater than the sum of the parts, offering more than a technical novelty. The annual calendar is adjusted on the basis of the local time, i.e. the date of the calendar is always indexed on the basis of the latter, and the calendar therefore adjusts itself forward or backward according to the change of the time zone, and of all times. where you plan to travel east or west of the globe.
Another topic of conversation is represented by the extreme cleanliness of the case design; if we exclude the small correctors on the side, all ordinary adjustment operations are performed using the crown, as in a classic Dual Time: the outermost position of the crown allows you to adjust the home time and the intermediate time to local time. Two small openings on the dial, indicated by the words “Home” and “Local” indicate in which span of 24 hours we are in one or the other destination.
Mechanical complication then, but extreme purity of the dial, finally, in which Patek proves to seek an identity of vintage but sporty rather than classic taste. The base is anthracite gray with black shades on the edge and applied Arabic numerals filled with beige luminescent material. Perhaps we need to get used to the texture on the dial which is hardly associated in a natural way with an exquisitely Calatrava watch, with “Clous de Paris” worked sides. Patek also presented a time-only reference in white gold with the same “texture”, but the two models differ in size and, obviously, in the origin of the caliber.
The Travel Time Annual Calendar Ref. 5326G-001 measures 41 mm in width, excluding crown, and 11.07 mm in thickness. The Patek caliber 31-260 PS QA LU FUS 24H, endowed with eight patents, has a fine hand-finished curved bridge architecture and the micro-rotor is in platinum. It is overall very balanced and technically satisfying. The price is equal to 69.930 euros. best replica watches sites to buy from
